The Ford F-150 Raptor Suspension Lift Kit - 1-3" Lift - Stage 4 by ICON is the ultimate suspension upgrade for your 2021-2025 Ford F-150 Raptor. Designed with precision and durability in mind, this kit brings improved performance capabilities to your Raptor, allowing for both on-road comfort and off-road prowess.

Developed through extensive research and testing, the ICON Ford F-150 Raptor Suspension Lift Kit is engineered to provide a significant performance enhancement over factory components. This kit takes advantage of the advanced 4-link and coil-sprung rear suspension system of the third generation Raptor, which is designed for high-speed and off-road capability. With its 1-3" adjustable lift, this suspension kit offers improved clearance and ride quality, ensuring your Raptor can tackle challenging terrains with ease. The billet upper control arms and overland rear springs work together to optimize wheel alignment and vehicle stability, resulting in a controlled and responsive driving experience both on and off the road.

Features

• Adjustable 3.0” diameter coilovers offering 1-3” of front lift height
• ICON's Compression Damping Electronic Valve (CDEV) technology for in-vehicle adjustment
• Billet upper control arms for enhanced strength and longevity
• Overland rear springs designed for load and travel versatility

For Raptor enthusiasts looking to enhance their vehicle’s capabilities, this Suspension Lift Kit represents an ideal solution that balances performance and reliability. We invite you to experience the transformation that this kit can bring to your driving adventures. If you have any questions or need more information, please don't hesitate to contact us directly. We have two facilities ready to assist you with installation and customization services—one in Austin, Texas and another in the Los Angeles, California area. Call us at 512-982-9393 (TX) or 562-981-6800 (CA).

Notes

• OEM Wheels & Tires Fitment: Yes
• Recommended Aftermarket Wheels: ICON Alloys - 17x8.5" w/ 5” Backspace / 6mm Offset
• Recommended Aftermarket Wheels: ICON Alloys - 18x9" w/ 5.25” Backspace / 6mm Offset
• Recommended Aftermarket Tires: 35" x 12.50" (37" or larger tires require coilover bump stop spacers along with trimming and modifications)
• Shocks are fully serviceable
• Requires recalibration of Advanced Driver Assistance Systems (ADAS) after install
• Do not combine with coil spacers or damage may occur
• Advertised lift height ranges are for a vehicle with approx 300lbs of additional weight in rear. Increasing or decreasing weight of vehicle due to accessories will alter lift range.
• An iOS operated device is required to run ICON Intelligent Control app
• When running 37" tires use up travel limiters part number 611077 in the front
• When running larger than 37" tires, or for very aggressive off-road use with 37" tires, use up travel limiters part number 611078 in the front
• Not compatible with OE rear coils. Shock length requires ICON rear coil springs part number 95230 or 95231.
• APPLICATION NOTE #230: Not compatible with F-150 Raptors equipped with dual coil shock absorbers

System Components

(qty: 1) | 21-25 F-150 RAPTOR FRONT 3.0 VS RR CDEV COILOVER KIT

(qty: 1) | 15-23 F150 & 17-22 FSD IIC INSTALL KIT

(qty: 1) | 21-24 RAPTOR BILLET UCA DJ PRO KIT

(qty: 1) | 21-25 F-150 RAPTOR SOLENOID MOUNT KIT

(qty: 1) | 21-25 F-150 RAPTOR TRIPLE RATE OVERLAND REAR COIL SPRING KIT

(qty: 1) | 21-25 F-150 RAPTOR DRIVER REAR 3.0 ZETA RXT RR CDEV

(qty: 1) | 21-25 F-150 RAPTOR PASSENGER REAR 3.0 ZETA RXT RR CDEV
